LigoWave APC Button AF | Punkt dostępowy | 2,4GHz 2x2 MIMO, 1x
LigoWave APC Button AF | Punkt dostępowy | 2,4GHz 2x2 MIMO, 1x RJ45 100Mb/s

LigoWave APC Button AF | Punkt dostępowy | 2,4GHz 2x2 MIMO, 1x RJ45 100Mb/s

KOD: LIGOWAVE APC BUTTON AF
244,81
BRAK NA MAGAZYNIE
send SPRAWDŹ KOSZT DOSTAWY
sentiment_very_satisfied star_border star_border star_border star_border star_border
Częstotliwość pracy: 2.4 GHz
Ilość portów LAN: 1x [10/100M (RJ45)]
Ilość portów WAN: Nie dotyczy
Standard sieci LAN: Fast Ethernet 10/100Mb/s
more POKAŻ WIĘCEJ PARAMETRÓW

APC BUTTON AF

The APC Button af is a small, robust and high performance 2.4 GHz indoor access point designed for SOHO and small to medium size enterprise applications. Unobtrusive design and operational robustness make it ideal for permanent installations on high walls or ceilings.

This product is equipped with a high output power (up to 23 dBm) 802.11n MIMO radio which allows effective commu- nication with older 802.11b/g equipment as well as newer standards based devices.

Dual firmware image will allow safe software upgrades. The device will restart using the prior working firmware in the unfortunate event of an upgrade failure. 802.3af standard support allows powering the device with PoE switches and makes installation easy by running a single cable from a switch.

The APC Button uses an advanced and feature-rich operat- ing system which supports bridge/router and repeater modes (repeater mode allows the product to operate as an access point and as a station at the same time). It also provides a user-friendly Adobe Flex based GUI with instant reconfiguration (without a reboot), installation tools (site survey, delayed reboot, spectrum analyzer, ping, tracer- oute) and is compatible with our standalone and cloud based Wireless Network Management System (WNMS).

Wireless

WLAN standard

IEEE 802.11 b/g/n

Radio mode

MIMO 2x2

Operating modes

Access point (auto WDS), Station, Station WDS, Repeater

Radio frequency band

2.402 - 2.484 GHz

Transmit power

Up to 23 dBm (country dependent)

Receive sensitivity

Varying between -94 and -74 dBm depending on modulation

Channel size

20, 40 MHz

Modulation schemes

802.11 g/n: OFDM (64-QAM, 16-QAM, QPSK, BPSK)

802.11 b: DSS (CCK, DQPSK, DBPSK)



Data rates

802.11 n: 300, 270, 240, 180, 120, 90, 60, 30 Mbps

802.11 g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps

802.11 b: 11, 5.5, 2, 1 Mbps

Error correction

FEC, Selective ARQ

Duplexing scheme

Time division duplex

Antenna

Type

2 x internal omni-directional antenna

Gain

3 dBi

Wired

Interface

10/100 Base-T, RJ45

Networking

Operating modes

Bridge, Router

WAN

Static IP, DHCP client, PPPoE client

NAT

Routing w/ or w/o NAT

Static routing

Supported

DHCP

Client, Server, Relay

Port forwarding

Supported

VLAN

Supported for management and data

User isolation

Supported

Softwave

General

Ability to define/limit frequency, channel width, EIRP, modulation

Advanced wireless functionality

ATPC (automatic transmit power control), auto - channel, auto - modulation

Operating mode

Router, Bridge

Wireless operating modes

AP auto WDS, station,station WDS, virtual radios (VSSID), repeater

Wireless security

WPA/WPA2 Personal, WPA/WPA2 Enterprise, WACL, User isolation, UAM (web portal authentication)

Wireless QoS

WMM

WAN protocols

Static IP, DHCP client, PPPoE client

Network

NAT, static routing, firewall, port forwarding, VLAN, traffic shaping

Services

DHCP server, SNMP server, NTP client, Alerts, Remote syslog, Wireless and Ethernet statistics, bandwidth limiting

Tools

Site survey, link test, ping, traceroute, spectrum analyzer, delayed reboot

Management

HTTP(S) GUI, SSH CLI, SNMP read, WNMS, troubleshooting file, reset via ICMP

Physical

Dimensions

Length 103 mm (4.05 ‘’), width 103 mm (4.05 ‘’), height 29 mm (1.14 ‘’)

Weight

86 g (3.03 oz)

Power supply

Not included in the package

Power source

48 VDC PoE (802.3af), also works with 48 V passive PoE adapters

Power consumption

3.6 W

Environmental

Operating temperature

0°C (32 F) ~ +55°C (+131 F)

Humidity

0 ~ 90 % (non-condensing)

Management

System configuration

User-friendly web GUI, Command line via SSH, centralized Wireless Network

Management System, reset via reset tool

System monitoring

SNMP v1/2c/3 server, Syslogs, system alerts via e-mail and SNMP trap

Regulatory

Certification

FCC/CE/Safety/RoHS compliance
