Cambium EPMP Force 300-19 ROW | CPE | AC WAVE2 5GHz, 2x2 MIMO,
British (UK) / GBP / Prices without VAT
Cambium EPMP Force 300-19 ROW | CPE | AC WAVE2 5GHz, 2x2 MIMO, RJ45 1000Mb/s, 19dBi

Cambium EPMP Force 300-19 ROW | CPE | AC WAVE2 5GHz, 2x2 MIMO, RJ45 1000Mb/s, 19dBi

CODE: C050900C806A
108,83 GBP without VAT
Added to cart
-
+
PCS
AVAILABILITY:
local_shipping SHIPPING: 24h
Maximum wireless transmission speed: 600 Mb/s
Number of LAN ports: 1x 10/100/1000BaseTX (RJ45)
Operating frequency: 5 GHz
more SHOW MORE PARAMETERS
:

ABOUT PRODUCT

banner

Both wireless service providers and businesses around the world are looking for solutions that provide reliable connections in congested radio environments. As free bands become a scarce commodity, finding the right way for broadband is crucial for all low and high density projects. Cambium Networks introduces groundbreaking technology that delivers exceptional performance, resilience and coverage, even in the most congested environments. The combination of the latest 802.11ac Wave 2 technology with the proven ePMP line scalability of the Force 300-19 model provides pass capability of up to 600 Mbps. The Force 300-19 is a powerful and affordable subscriber module that works with the ePMP3000 access point and utilizes the forward compatibility feature, as well as providing support for ePMP 2000 products to facilitate migration to 802.11ac Wave 2 technology.
The Force 300-19 model has a integrated 19 dBi antenna with small beam width and IP67 protection class.

The printsheet

Features of ePMP Force 300-19 Cambium Networks

  • Designed to operate in harsh environments, this model delivers exceptional 600 Mbps of real user data throughput
  • Support for channel widths from 20 MHz to 80 MHz and modulation to 256 QAM
  • Real-time bandwidth monitoring without bandwidth reduction
  • Integrated 19 dBi panel antenna with low distortion coefficient and exceptional range
  • Configurable operating modes for easy adjustment to symmetrical and asymmetrical traffic, while maintaining high performance and a return delay of only 3-5 ms
  • QoS management for exceptional quality triple play services (VoIP, video and data) with three levels of traffic prioritization
  • Fast and reliable installation on poles or walls
  • Estimate performance and availability with Cambium Networks LINKPIanner™

SPECIFICATION

Features / filters
LAN standard Gigabit Ethernet 10/100/1000 Mb/s
Maximum wireless transmission speed 600 Mb/s
Number of LAN ports 1x 10/100/1000BaseTX (RJ45)
Operating frequency 5 GHz
Wireless network standards IEEE 802.11ac Wave 2
Antenna gain 11dBi - 20dBi
Device type Client device, Access point, Radioline,
Horizontal beamwidth 14.5°
MIMO Type 2x2
Region / power Cable ROW/EU
Type of device power supply Passive PoE
Working temperature -30°C to +60°C

PASMO

Distance between channels Configurable at 5 MHz intervals
Frequency range Broadband band 4910-5970 MHz (permitted frequencies and bands depending on national regulations)
Channel width 20 / 40 / 80
INTERFACE
MAC layer (Media Access Control) Cambium
Own physical layer 802.11ac Wave 2 (2x2 MIMO/OFDM)
Ethernet connection 10/100/1000 BaseT, Cambium PoE compliant and standard PoE connectors
VLAN 802.1Q with prioritization 802.1p
Protocols IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
EFFICIENCY
Network management IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro™
ARQ Yes
Nominal receiving sensitivity (with FEC) @20 MHz channel MCS0 = -89 dBm to MCS8 (256 QAM-3/4) = -68 dBm (per chain)
Nominal receiving sensitivity (with FEC) @ 40 MHz channel MCS0 = -87 dBm for MCS9 (256 QAM-5/6) = -66 dBm (per chain)
Nominal receiving sensitivity (with FEC) @ 80 MHz channel MCS0 = -84 dBm for MCS9 (256 QAM-5/6) = -61 dBm (per chain)
Modulation levels (adaptive) MCS0 (BPSK) to MCS9 (256 QAM-5/6)
Transmission power range 0 to +28 dBm (connected to regional EIRP limit) (1 dB interval)
PHYSICAL FEATURES
Security Integrated 1 J (C000000L065A - 30 V Gigabit surge protection is recommended for optimal protection)
Environmental IP55
Temperature -30°C to 60°C (-22°F to 140°F)
Weight 1.45 kg (3.2 lbs) - including mounting bracket
Wind resistance 180 km/h (112 mph)
Dimensions (diameter x depth) 27.8 x 27.8 x 4.5 cm (10.9 x 10.9 x 1.8") - without mounting bracket
Mounting on masts with diameter 2.5-4.1 cm with clamp; up to 5.7 cm with larger clamp
Power consumption 12 W
Input voltage Passive PoE (nominal 30 V DC); range 14-30 V DC
SAFETY
Encryption 128-bit AES (CCMP mode)
CERTIFICATES
FCCID Z8H89F0048
Industrial Canada Cert 109W-0048
CE EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)
ANTENNAE SPECIFICATIONS
Frequency range 4,9-5,970 MHz
Antenna type Panel
Maximum profit 19 dBi
3 dB bandwidth - azimuth 14.5 degrees
3 dB bandwidth - facade 12.5 degrees
PART NUMBER
C058900C801A ePMP 5GHz Force 300-19 SM (FCC) - US cable
C050900C801A ePMP 5GHz Force 300-19 SM (IC) - Canada/USA cable
C050900C802A ePMP 5GHz Force 300-19 SM (EU) - EU cable
C050900C803A ePMP 5GHz Force 300-19 SM (EU) - UK cable
C050900C804A ePMP 5GHz Force 300-19 SM (ROW) - without cable
C050900C805A ePMP 5GHz Force 300-19 SM (ROW) - US cable
C050900C806A ePMP 5GHz Force 300-19 SM (ROW) - EU cable
C050900C807A ePMP 5GHz Force 300-19 SM (ROW) - British cable
C050900C808A ePMP 5GHz Force 300-19 SM (ROW) - cable India
C050900C809A ePMP 5GHz Force 300-19 SM (India) - cable India
C050900C810A ePMP 5GHz Force 300-19 SM (ROW) - cable China
C050900C811A ePMP 5GHz Force 300-19 SM (ROW) - cable Brazil
C050900C812A ePMP 5GHz Force 300-19 SM (ROW) - cable Argentina
C050900C813A ePMP 5GHz Force 300-19 SM (ROW) - Australia/New Zealand cable
C050900C814A ePMP 5GHz Force 300-19 SM (ROW) - cable RPA
C050900C815A ePMP 5GHz Force 300-19 SM (ROW) - without power supply

SUPPORT

Downloads:

Product data sheet (ENG) Download

Cambium Networks ePMP 3000 webinar

P2P link configuration in Cambium systems

Introduction to ePMP systems
