Ubiquiti POE-24-24W-G | PoE Power supply | 24V, 1A, 24W, Gigabi
British (UK) / GBP / Prices without VAT
Ubiquiti POE-24-24W-G | PoE Power supply | 24V, 1A, 24W, Gigabit

Ubiquiti POE-24-24W-G | PoE Power supply | 24V, 1A, 24W, Gigabit

CODE: POE-24-24W-G / EAN: 810354023538
9,86 GBP without VAT
Added to cart
-
+
PCS
AVAILABILITY:
local_shipping SHIPPING: 24h
Output type of supply: PoE 1Gb/s
Output voltage: 24V
Power supply: < 25W
more SHOW MORE PARAMETERS

ABOUT PRODUCT

Equipment protection

The PoE adapters are highly reliable and, in combination with the Ubiquiti TOUGHC cable, provide earthing and surge protection to protect against electrostatic discharges (ESD). Output voltage is 24V. It is ideal for powering Ubiquiti devices, but it is also suitable for all devices powered by 24V via PoE. The power supply supports Gigabit network capacity.

ubiquiti networks POE-24-24W-G

SPECIFICATION

Features / filters
Output type of supply PoE 1Gb/s
Output voltage 24V
Power supply < 25W

Basic technical parameters
Dimensions 88 × 57 × 33 mm
Weight 158.5 g
Output voltage 24 V DC @ 1.0A
Gigabit LAN port YES
Remote reset YES
RESET button YES
Input voltage 90-260V AC @ 47-63 Hz
Input current 0.6A @ 120VAC,
0.4A @ 240VAC
Performance 80+%
Power supply Pins 1, 2, 4, 5 (+) and
Pins 7, 8, 3, 6 (-)
Ambient temperature during operation 0° to 40° C
Humidity during operation 35 to 95%
Connector AC IEC-320 C6
Ports Date IN / POE RJ45 Shielded sockets
Overvoltage protection YES
Response time <1 nS
Certificates IEC 60950-1:2005+A1UL60950-1 EN55022:2010, EN55024:2010 FCC Class B

SUPPORT

Datasheet Download

FAQ

What is the power of the power supply ?

Power supply < 25W

What can be the ambient temperature during operation ?

Ambient temperature during operation: 0° to 40° C

Does it have overvoltage protection ?

Yes
