VPRO 40 Ah series batteries are made in AGM (Absorbent Glass Mat) VRLA technology and are mainly designed for: use in emergency power supply systems (UPS, automation systems), solar installations and with voltage converters. They are best suited for buffer charging systems, but can also be used in applications where the batteries work cyclically. The battery has about 500 cycles, and battery life is from 5 to 8 years at a temperature of 20-25 degrees Celsius.
|Capacity (25°C)||45 Ah|
|Maximum charging current||12 A|
|Overall height||175 mm|
|Internal resistance (25°C)||9 mΩ at full charge|
|Self-discharge||2-3% per month at 25°C|
|Buffer charge||13.5 - 13.8 V (-18 mV/C)|
|Cyclical charging||14.5 - 15.0 V (-30 mV/C)|
|VOLT - Product Card OPTI 12V 45Ah EN||Download|
The design life of the battery is 5-8 years under optimal operating conditions specified by the manufacturer.
