Features:
- Converter 1/3'' 3Megapixel Aptina CMOS
- Compression H.264 & MJPEG
- 20fps 3MP(2048x1536)
- 3DNR (Digital Noise Reduction)
- Mechanical ICR filter
- Max. IR LEDs length 30m
- Build-in WEB Server
- Comply with NVR, CMS (PSS/DSS) & DMSS
- Vandal proof enclosure
- 2.8-12mm fixed lens F1.8
- Power supply DC12V and PoE
Specifications:
Model | BCS-DMIP3300IR-E | |
Scane System | Progressive scane | |
Image Sensor | 1/3” 3Megapixel PS Aptina CMOS | |
Effective Pixels | 2048(H) x 1536(V) | |
Sensitive | Colour: 0.1Lux/F1.6; 0Lux/F1.2 (IR On) | |
S/N | > 50dB (AGC off.) | |
WB (ATW) | automatic/manual | |
General features | Lens | 2,8mm F1.8 |
BLC | Off. – on (BLC) | |
Snapshot | Auto, Manual (1/50-1/10000), Protection against fibrillation | |
AGC | Off – on | |
DNR | 3D Off – on operate only with AGC | |
Additional features | Motion detection | On./Off. (adjust the position, size, sensitivity 4 detection areas) |
Reserved area | On./Off. 4 areas | |
Mirror reflection | On./Off. | |
Sharpness | On./Off.– smooth regulation | |
IR LEDs length | 30m | |
Day/Night | Mechanical IR filter (ICR) | |
Video features | Compression | H.264 / MJPEG |
Resolution | 3Mpx(2048x1536) / 1080P(1920x1080) / 720P(1280x720) / D1(704x576) / CIF(352x288) | |
Main stream transmission speed | 3M(1~20fps) / 1080P(1~25/30fps) / 720P(1~25/30fps) | |
Under stream transmission speed | D1/CIF(1 ~ 25/30fps) | |
Throughput | H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 12288Kbps | |
Network features | Connector type | RJ-45 (10/100Base-T) |
Protocols | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour | |
ONVIF | ONVIF Profile S | |
Mobile Users | iPhone, iPad, Android, Windows Phone | |
Users | Max 10 logged | |
Power Supply | 12VDC / POE (802.3af) | |
Power Consumption | 5 W with IR on | |
Working Environment | -30°C ~ +60°C, IP66, IK10 | |
Weight | 0,39kg | |
Dimensions DxH | O110x81mm | |
