| Beam shaping |
Supported |
| Simultaneous customers |
256 |
| MIMO, we're streaking |
2x2:2 MU-MIMO |
| Channel width |
20 MHz, 40 MHz, 80 MHz |
| Standards |
fuIEEE 802.11a/b/g/n/ac Wave2
IEEE 802.11d/e/h/i/k/r/u/v/w
Modulation: BPSK, QPSK, CCK, 16/64/256-QAM
Radio modes: DSSS, OFDM |
| Transmission power range |
2.4 GHz: 24dBm, 5 GHz: 25 dBm (total conduction) |
| Antenna gain |
2.4 GHz: 5.25 dBi, 5GHz: 5.5 dBi |
| Max. transmission speed |
2.4 GHz: 400 Mbps, 5 GHz: 867 Mbps |
| Antenna |
Two-polar, omnidirectional, integrated |
| SSID |
16 SSID per 2 radio units |
| Radio functions |
Maximum Ratio Combining (MRC)
Cyclic Delay/Shift Diversity (CDD/CSD) support
Space-Time Blocking Coding (STBC)
Low-Density Parity Check (LDPC) |
| Ethernet ports |
One with Auto MDIX Gigabit Ethernet Auto Detection (10/100/1000 Mbps) RJ45 port |
| Wi-Fi Alliance |
Wi-Fi certified a/b/g/n/ac WPA2-Enterprise, Personal WMM, Passpoint |
| Power supply |
802.3af PoE power supply or PoE-powered switch |
| Working humidity |
10% to 95%, non-condensing |
| Operating temperature |
0°C to 50°C (32°F to 122°F) |
| Weight |
384 g (0,86 lb) |
| Frequency bands |
2,400 to 2,2484 GHz
5,150 - 5,250 GHz
5.725 to 5.850 GHz
5,250 - 5,350 GHz
5,470 - 5,725 GHz |
| Dimensions |
17.0 x 17.0 x 4.1 cm (6.7 x 6.7 x 1.61") |
| Power consumption |
13 W (max.) |
| Safe installation |
Kensington Key Slot |
| Reset button |
Available at |
| LED |
Three-colour LEDs controlled from the software item |
| MTBF |
1.507.537 h at 50°C, 4.431.480 h at 25°C |
| Certificates |
FCC, CE, IC, UL
EN60601-1-2 (Medical EMC)
Compliant with UL2043 WEEE/RoHS Plenum |
| Mounting options |
Wall and ceiling - mounting bracket, desktop option
T-bar support: 14 mm, 24 mm, 38 mm |
| Management modes |
cnMaestro cloud management
Self-contained local controller cnMaestro VM
Autopilot (access point as a controller for networks up to 32 access points)
Standalone via Access Point GUI (http/https), CLI (telnet/ssh) |
| Radio management |
AutoRF automatic channel and power management |
| AAA support |
Authentication, access control, dynamic
RADIUS authorisation (CoA, DM)
Server emergency switchover, load balancing |
| Customer isolation |
At the access point, throughout the network |
| QoS |
802.11e/WMM QoS, DSCP/ToS mapping |
| Grid |
WDS Mesh unit and multistage |
| Ethernet services (L2) |
802.1p/802.q, RADIUS with assigned VLAN, VLAN to SSID, VLAN pooling, LLDP, IGMP Snooping (v1/v2/v3) |
| Network services |
NAT, DHCP server |
| MAC Authentication |
Filtering list at the access point
MAC filtering list in the controller
RADIUS MAC Authentication
Forwarding MAC authentication to the Captive Portal |
| Firewall |
Layer 2 (L2), layer 3 (L3) and DNS ACL
DoS Protection |
| 3G/4G/LTE Offload |
Passpoint (Hotspot 2.0) |
| DHCP |
Supported
|
| External NMS monitoring |
SNMP v1, v2c, v3 |
| Customer API |
Customer presence/location API
DNS, NAT and TCP Connecting Logging |
| Time synchronization |
Automatic (from controller), NTP |
| Diagnostic tools |
Packet Capture, Spectrum Analyzer, DNS check
Ping, Traceroute, Syslog, Speedtes |
| Traffic tunnelling |
L2TP, L2oGRE, PPPoE |
| Transmission speed (Mbps) |
802.11a: 6, 9, 12, 18, 24, 36, 48, 54
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54
802.11n (2.4 GHz): 6.5 to 400
802.11ac (5 GHz): 6.5 to 866.7 |
| Flexible installation |
Cloud management
|
| Network management |
Centralized configuration, statistics, events, firmware |
| Hierarchical views |
Network topology mapped to objects and floors
|
| Floor plans |
Transmission of individual floor plans and mapping of access points |
| Integrated guest portal |
OTP SMS authentication payment gateways support voucher-based authentication with social networking login |
