Aruba 2930 48G 4SFP | Switch | 48x RJ45 1000 Mb/s, 4x SFP
CODE: JL260A
EN
TheAruba 2930F JL260A continues the line of switches targeted at mobile users. This model operates at Layer 3 switching. It is designed for small and medium-sized businesses and is optimally suited for small offices and branch offices. The platform features easy configuration and deployment, the latest management and security mechanisms, and high performance. All options are available to owners right from the start and no additional licensing is required.
Basic general data | |
Manufacturer | Aruba |
Model | 2930F 48G 4SFP |
Model code | JL260A |
Type | Switch |
Ports | |
Number of ports | 48 x RJ-45 autosensing 10/100/1000 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 4 x SFP 1/10GbE ports; PHY-less |
Additional Ports and Slots | 1 dual personality (RJ-45 or USB micro-B) serial console port |
Physical properties | |
Dimensions | 44.25 x 24.63 x 4.39 cm 1U |
Weight | 3.1 kg |
Memory and processor | |
CPU | Dual Core ARM Cortex A9 @ 1016 MHz |
RAM | 1 GB DDR3 SDRAM |
Packet buffer size | 12.38 Mb |
Storage | 4GB eMMC |
Performance | |
Capacity | 77.4 Mpps |
Stacking capacity | 104 Gbps |
Routing table size | 2,000 IPv4, 1,000 IPv6 in hardware, 200 OSPF, 256 Static, 10,000 RIP |
MAC address table size | 32768 entries |
Environment | |
Operating temperature | 32°F to 131°F (0°C to 55°C) |
Relative humidity during operation | 15% to 95% (non-condensing) |
Idle/storage temperature | -40°C to 70°C |
Electrical characteristics | |
Frequency | 50/60 Hz |
Maximum heat dissipation | 100,0 BTU/h (105,5 kj/h) |
Voltage | 100 - 127 / 200 - 240 VAC, rated |
Current | 0.9/0.6 A |
Maximum rated power | 46.6 W |
Idle power | 32.7 W |
Notes | Idle power is the actual power consumption of the device when no ports are connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers predicted for infrastructure planning at full PoE load (if equipped), 100% traffic, all ports connected and all modules populated. |
Data sheet | Download |
Aruba 2930F 48G 4SFP does not have PoE ports.
