HG8240F is an optical network terminal (ONT) designed for home users and small and large offices. The HG8240F terminal is a high-end FTTH home solution. The device provides two POTS ports, four FE Internet ports. It has high-performance forwarding functions to provide a great experience for VoIP, Internet and HD video services.
A natural heat sink material is used on the top of the terminal case, and the optical port has a dustproof design with a rubber plug. The HG8240F is both pleasing to the eye and energy efficient. It can be installed on a desk or on a wall. Using Gigabit Passive Optical Network (GPON) technology, the HG8240F provides high-speed data connectivity over a single optical fiber with uplink speeds of 1.244Gbps and downlink speeds of 2.488Gbps.
Technical data | |
Model | HG8240F |
Operating temperature | 0°C to 40°C |
Operating humidity | 5% RH to 95% RH (non-condensing) |
Power supply input | 100-240 V AC, 50/60 Hz |
System power supply | 11-14 V DC, 1 A |
Static power consumption | 5.5 W |
Maximum power consumption | 7.5 W |
Ports | 4FE 2POTS |
Connector type | SC/UPC |
Colour | White |
