Totolink X6100UA is a new USB Wi-Fi Adapter that complies with the latest Wi-Fi 6 standard (IEEE802.11ax), offering Wi-Fi speeds of up to 1201Mbps in the 5GHz band and 573.5Mbps in the 2.4GHz band. With this adapter, any application will be more productive with drastically increased Wi-Fi speeds. Both the 2.4GHz and 5GHz bands have been upgraded to the latest generation - perfect for 4K streaming, online gaming and fast downloads.
The X6100UA uses two high-gain antennas implemented in a single design to increase the speed and range of data transmission. With Totolink X6100UA, you will forget about having to be near a router, as it makes the connection fast and stable in every room of your house.
The MU-MIMO technology used in the Totolink X6100UA router creates two parallel data streams, increasing bandwidth and improving network performance in cooperation with the MU-MIMO router. And with an omnidirectional antenna that can be easily adjusted in all positions, Totolink X6100UA provides convenience even in tight spaces.
| Features / filters | |
| LAN standard | Not applicable |
| Maximum wireless transmission speed | 1800 Mb/s |
| Number of LAN ports | Not applicable |
| Number of WAN ports | Not applicable |
| Operating frequency | Dual Band (2.4GHz, 5GHz) |
| Wireless network standards | IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a, IEEE 802.11ax, |
| Antenna | Yes |
| Antenna design | External & Internal |
| Antenna direction type | Omni-directional |
| Antenna gain | Under 10dbi |
| Antenna type | Outside |
| Application | Indoor |
| Built-in modem | None |
| Component for | PC/notebook |
| Connectivity technology | Wired & Wireless |
| Depth | 30 |
| Detachable antennas | Yes |
| Ethernet LAN | No |
| Height | 18 |
| Host interface | USB |
| Interface | WLAN |
| Internal | No |
| LED indicators | Wi-Fi |
| Management | By web browser |
| Maximum data transfer rate | 1774.5 |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Operating relative humidity (H-H) | 5 - 95 |
| Operating temperature (T-T) | 0 - 50 |
| Plug and Play | Yes |
| Product colour | Black |
| Quick installation guide | Yes |
| Storage relative humidity (H-H) | 5 - 95 |
| Storage temperature (T-T) | -40 - 70 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Type of case | Plastic |
| Type of device power supply | USB port |
| USB ports quantity | 1 |
| USB powered | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Width | 100 |
| WiFi encryption | WEP, WPA-PSK, WPA-PSK/WPA2-PSK, WPA/WPA2, WPA3, |
| Basic general data | |
| Manufacturer | Totolink |
| Model | X6100UA |
| Type | USB WiFi adapter |
| Hardware features | |
| Interface/button | 1 x USB3.0 1 x WPS |
| LED indicators | 1 x Wireless (ACT) Blue |
| Antenna | 1 x external dual-band antenna 1 x internal dual band antenna |
| Dimensions (L x W x H) | 100 x 30 x 18mm (USB housing) 130 x 15 x 16mm (antenna) |
| Wireless functions | |
| Standards | IEEE 802.11ax IEEE 802.11ac IEEE 802.11n IEEE 802.11g IEEE 802.11b IEEE 802.11a |
| RF frequency | 2.4GHz/5GHz |
| Data transmission speed | 5 GHz: Up to 1201 Mbps 2.4 GHz: Up to 573.5 Mbps |
| Wireless network security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES), WPA3 |
| Other functions | |
| Contents of the package | 1 x X6100UA USB WiFi adapter 1 x Quick Installation Guide 1 x CD |
| System requirements | Supports Windows 10 (32/64 bit), Win8/8.1 (32/64 bit), Windows 7 (32/64 bit) |
| Environment | Operating temperature: 0℃~50℃ (32 ℉~122℉) Storage temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating humidity: 5%~95% non-condensing Storage Humidity: 5%~95% non-condensing |
The Totolink X6100UA's built-in USB 3.0 port allows for faster data transfer and reduced latency.
