MikroTik RB1100AHx4 | Router | 13x RJ45 1000Mb/s, 1x microSD, 2x SATA 3, 2x M.2
EAN: 4752224002662
Reference: RB1100X4
1,051.67 zł gross gross / meter 855,02 zł netto gross / piece
Warranty and service support
Available options and delivery cost
Same-day shipping
Payments methods

Powerful network management device
RB1100AHx4 router has 13x Gigabit Ethernet ports. The router is powered by the Annapurna Alpine AL21400 processor with four cores Cortex A15, clocked at 1.4 GHz each, for maximum throughput up to 7.5 Gbit. The device supports hardware IPsec acceleration (up to 2.2Gbps with AES128).

Universal design
The device is supplied with a rack 1U enclosure, a serial RS232 port and dual redundant power supplies (with -48v DC power supply and 802.3at/af support).

Height 47 mm
Antenna type Not supported
LED indicators Activity
Width 444 mm
Depth 148 mm
Cables included AC
Rack mounting Yes
Power consumption (typical) 20 W
Harmonized System (HS) code 85176990
Ethernet LAN (RJ-45) ports 13
Flash memory 128 MB
DC-in jack Yes
Performance 7.5 Gb/s
Operating temperature (T-T) -40 to 70 °C
Cabling technology 10/100/1000Base-T(X)
Rack capacity 1U
RS-232 ports 1
Ethernet interface type Gigabit Ethernet
Firmware upgradeable Yes
Processor frequency 1400 MHz
Web-based management Yes
Compatible memory cards MicroSD (TransFlash)
Operating system installed RouterOS
Power over Ethernet (PoE) Yes
Internal memory 1000 MB
Temperature monitoring Yes
Voltage monitoring Yes
Ethernet LAN Yes
AC input voltage 100 V
SIM card slot No
Processor cores 4
Processor model Annapurna Labs Alpine AL21400
Power source type AC
Built-in processor Yes
Storage media Flash
Product colour Stainless steel
IP address filtering Yes
Ethernet WAN Yes
3G/4G USB modem compatibility No
DSL WAN No
