TP-Link TL-SG1024D | Switch | 24x RJ45 1000Mb/s, Rack/Desktop, Unmanaged

EAN: 6935364020620

Reference: TL-SG1024D

435.37 zł gross gross / meter 353,96 zł netto gross / piece

Availability No product

Payments methods

przelewy.jpg google-pay.jpg apple-pay.jpg mastercard.jpg visa.jpg blik.jpg mbank.jpg paypo.jpg payu.jpg

24-port Gigabit switch TL-SG1016D from TP-Link

TP-Link TLSG1024D is a switch to support Gigabit Ethernet connection. All 24 ports are equipped with a MDI/MDIX automatic crossover function, which allows for quick installation without checking the type of cable used. The device is based on the innovative Green TP-Link technology which saves up to 15% of the energy used and 80% of the materials used in the packaging are recyclable.

High network capacity

The TL-SG1024D 10/100/1000 Mbps guarantees bandwidth at the business level, allowing users to transmit large files instantly. The switch supports jumbo frames up to 10 KB, which significantly increases the transmission speed of larger files, and the IEEE 802.3x flow control system for full duplex mode and the backpressure function for half duplex ensure efficient operation. All users, working at home or in workgroups in office or production environments, can now transfer bandwidth-intensive files seamlessly.

Green TP-Link

TL-SG1024D SWITCH is based on Green TP-Link technology, which effectively increases network capacity while saving energy. The device independently adjusts power consumption depending on connection status and cable length. The switch complies with the European RoHS directive, which limits the use of equipment made of environmentally hazardous materials.

Trouble-free installation

The switch has a plug and play function for simple and seamless installation without additional software. The MDI/MDIX function eliminates the need for cross-over cables and automatically negotiates connections detects on each port the speed of the connected device (10, 100 or 1000 Mb/s), guaranteeing the best transmission performance.

Regulatory Approvals FCC, CE, RoHS
Storage relative humidity (H-H) 5 – 90%
Power source mains electricity
Height 44 mm
LED indicators Yes
Bandwidth 48 Gb/s
Width 294 mm
Depth 180 mm
Connectivity technology Wired
Auto-negotiation Yes
Power management 100 - 240 V, 50/60 Hz
Storage temperature (T-T) -40 to 70 °C
Cables included AC
Rack mounting Yes
Maximum data transfer rate 1 Gb/s
Power consumption (max) 13.62 W
Package weight 1950 g
Humidity measurement range 10 – 90%
Operating temperature (T-T) 0 – 40 °C
32 – 104 °F
Harmonized System (HS) code 85176990
Networking features Gigabit Ethernet
Switching capacity 48 Gb/s
Networking standards IEEE 802.3ab
Switch type Unmanaged
10G support No
Full duplex Yes
Auto MDI/MDI-X Yes
Supported data transfer rates 10/100/1000 Mbps
Package depth 400 mm
Package height 80 mm
Heat dissipation 46.44 British thermal unit per hour
Package width 250 mm
Quality of Service (QoS) support Yes
Package type Box
Rack mount kit Yes
Supported network protocols CSMA/CD, TCP/IP
User guide Yes
Flow control support Yes
Jumbo frames 10000
Jumbo frames support Yes
MAC address table 8000 entries
Power supply included Yes
Power over Ethernet (PoE) No
AC input frequency 50 Hz
AC input voltage 100 V
Gigabit Ethernet (copper) ports quantity 24
Cable types supported Cat3
Store-and-forward Yes
Product colour Grey
Power connector DC-in jack
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 24
Stackable Yes
Product dimensions (WxDxH) 294 mm
Connectivity LEDs Y
