MikroTik Chateau LTE18 ax | LTE Router | S53UG+5HaxD2HaxD-TC&EG18-EA, Wi-Fi 6, 4x RJ45 1000Mb/s, 1x RJ45 2.5Gb/s

CODE: S53UG+5HAXD2HAXD-TC&EG18-EA / EAN: 4752224007889

MikroTik Chateau LTE18 ax | LTE Router | S53UG+5HaxD2HaxD-TC&EG18-EA, Wi-Fi 6, 4x RJ45 1000Mb/s, 1x RJ45 2.5Gb/s

CODE: S53UG+5HAXD2HAXD-TC&EG18-EA / EAN: 4752224007889
201,44 GBP without VAT (net)
3G/4G USB modem compatibility: Yes
4G standard: LTE-TDD & LTE-FDD
AC adapter included: Yes
Show more parameters

About product

Fast and Reliable Internet Access - MikroTik Chateau LTE18 AX

MikroTik Chateau LTE18 AX (S53UG 5HaxD2HaxD-TC

Powerful Processor and Large RAM

The Chateau LTE18 AX is equipped with a state-of-the-art quad-core IPQ-6010 processor running at 1.8 GHz and 1 GB of RAM. This allows it to efficiently manage complex operations such as advanced firewall rules, IPsec hardware encryption and the use of multiple threads. With support for advanced WPA3 encryption, users can feel more secure than ever before.

Unprecedented Speed with WiFi 6

The Chateau LTE18 AX supports the latest WiFi 6 (802.11ax) and Wave 2 wireless standard, providing unprecedented connection speeds. Compared to previous generations, the Chateau LTE18 AX achieves up to 40% faster speeds in the 5 GHz band and up to 90% faster speeds in the 2.4 GHz band. With 4x4 MIMO on LTE and four built-in LTE antennas with 4 dBi energy gain, the device guarantees excellent coverage throughout the home.

Versatile Features and Connectors

The Chateau LTE18 AX offers a wide range of connectors, including 4 Gigabit Ethernet ports, 1 2.5 Gigabit Ethernet port, a USB port and a microSIM slot. This makes it extremely versatile and can meet a variety of user requirements. The device also supports 2x2 MIMO on both bands, with a maximum theoretical throughput of 574 Mbps for 2.4 GHz and 1201 Mbps for 5 GHz.

Ideal for Operators and Advanced Users

The Chateau LTE18 AX is an excellent choice for mobile operators who can use TR-069 technology to remotely manage customers' devices. Advanced users and network enthusiasts can enjoy the advanced functionality of RouterOS. Meanwhile, a simple and straightforward website is available for households.

Specification

Features / filters
3G/4G USB modem compatibility Yes
4G bands supported 700,800,850,900,1800,2100,2300,2500,2600
4G standard LTE-TDD & LTE-FDD
AC adapter included Yes
Antenna design External
Antenna gain level (max) 6
Antennas quantity 2
Built-in processor Yes
Cables included UTP
Cabling technology 10/100/1000Base-T(X)
Certification CE, EAC
DC-in jack Yes
Depth 156
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 4
Ethernet LAN data rates 2500
Ethernet LAN interface type Ethernet
Ethernet WAN Yes
External power adapter Yes
Flash memory 128
GSM bands supported 850,900,1800,2100
Height 44
Internal memory 128
Mobile network generation 4G
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Operating temperature (T-T) -40 - 65
Output voltage 12 - 28
Power consumption (typical) 16
Power source type DC
Processor cores 4
Processor frequency 864
Product colour White
Product type Tabletop router
Quality of Service (QoS) support Yes
RAM capacity (Wi-Fi point) 1000
Reset button Yes
Short Message Service (SMS) Yes
SIM card slot Yes
SIM card type MicroSIM
Sustainability certificates RoHS
Top Wi-Fi standard Wi-Fi 6 (802.11ax)
USB 2.0 ports quantity 1
USB port Yes
Wall mountable Yes
WAN connection type RJ-45
Wi-Fi band Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Width 240
WLAN data transfer rate (first band) 574
WLAN data transfer rate (max) 1200
WLAN data transfer rate (second band) 1200

Processor IPQ-6010
S53UG 5HaxD2HaxD-TC
Number of processor cores 4
Clocking 1800 MHz
RAM 1 GB DDR3L
Built-in memory 128 MB
Type of built-in memory NAND
Ethernet interface 4x Gigabit Ethernet 10/100/1000 Mbps ports
1x 2.5 Gigabit Ethernet port
USB ports 1x USB 3.0 type A port
SIM slots 1x microSIM slot
WiFi operating bandwidth 2.4 and 5 GHz
Polarity (WiFi) 2x2 MIMO / dual chain
WiFi standards 2.4 GHz: 802.11 b/g/n/ax
5 GHz: 802.11 a/n/ac/ax
Energy gain of WiFi antennas 2.4 GHz (3 dBi)
5 GHz (6 dBi)
Type of WiFi antennas Built-in, omnidirectional
LTE category 18, 4x4 MIMO
Max theoretical LTE throughput Data downloads: 1200 Mbps
Data sending: 150 Mbps
LTE bands 1, 3, 5, 7, 8, 20, 28, 38, 40, 41
LTE aggregation Yes
TAC 86981604
Energy gain of LTE antennas 4 dBi
Method of power supply DC socket 12 - 28 V
Power supply 24 V 1.2 A
Max power consumption 23 W (17 W no load)
Operating system RouterOS version 7.0 (compatible only with version 7 and later)
Dimensions 240 x 156 x 44 mm
Permissible operating temperature From -40 to 65 degrees C
Supported LTE bands
Modulation Downlink: 256 QAM
Uplink: 64 QAM
LTE FDD 1 (2100)
3 (1800)
5 (850)
7 (2600)
8 (900)
20 (800)
28 (700)
LTE TDD 38 (2600)
40 (2300)
41 (2500)
3G 1 (2100)
3 (1800)
5 (850)
8 (900)
Supported bands 2x CA (uplink) B3 B3
B7 B7
B38 B38
B40 B40
B41 B41
Supported 4x4 MIMO LTE bands (downlink) LTE-FDD: B1 / B3 / B7
