WI-FI 802.11ac support allows the Archer T3U Plus to run 3 times faster than previous N standards. High-speed WI-FI(up to 867 Mbps at 5 GHz and 400 Mbps at 2.4 GHz) allows you to perform all the online tasks you need, including watching HD videos and playing online games.
Archer T3U Plus uses two high-gain antennas implemented in a single design, which increases the speed and range of data transmission. With Archer T 3U Plus you will forget about having to be near the router, now your connection is fast and stable in every room in your house.
The MU-MIMO technology of the TP-Link Archer T3U Plus creates two parallel data streams, increasing bandwidth and improving network performance in partnership with the MU-MIMO router. And with an omnidirectional antenna that can be easily adjusted in all positions, the TP-Link Archer T3U Plus provides convenience even in tight spaces.
| Features / filters | |
| Antenna | Yes |
| Antenna design | External |
| Antennas quantity | 2 |
| Bandwidth (first) | 2.4 |
| Bandwidth (second) | 5 |
| Certification | FCC, CE, RoHS |
| Component for | PC/notebook |
| Connectivity technology | Wireless |
| Depth | 18.2 |
| Frequency range | 2.4 - 5 |
| Full duplex | Yes |
| Height | 173.4 |
| Host interface | USB |
| Interface | WLAN |
| Internal | No |
| LED indicators | Status |
| Maximum data transfer rate | 867 |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Operating relative humidity (H-H) | 10 - 90 |
| Operating temperature (T-T) | 0 - 40 |
| Package depth | 148 |
| Package height | 42 |
| Package type | Box |
| Package weight | 150 |
| Package width | 207 |
| Plug and Play | Yes |
| Product colour | Black |
| Quantity per pack | 1 |
| Quick start guide | Yes |
| Security algorithms | WEP,WPA,WPA-PSK,WPA2,WPA2-PSK |
| Storage relative humidity (H-H) | 5 - 90 |
| Storage temperature (T-T) | -40 - 70 |
| Sustainability certificates | RoHS |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| USB powered | Yes |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Width | 57.8 |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Wind |
| WLAN data transfer rates supported | 11,54,300,400,867 |
| Basic general data | |
| Manufacturer | TP-Link |
| Model | Archer T3U Plus |
| Type | USB WiFi adapter |
| Hardware features | |
| Ports | USB 3.0 |
| LEDs | Status |
| Dimensions | 57.8 × 18 × 173.4 mm (2.28 × 0.71 × 6.83 inches) |
| Antenna | 1 high-gain external antenna |
| Wireless transmission characteristics | |
| Wireless standards | IEEE 802.11b/g/n 2.4 GHz, IEEE 802.11a/n/ac 5 GHz |
| Transmission speed | 5 GHz 11ac: up to 867 Mbps (dynamic) 11n: up to 300 Mbps (dynamic) 11a: up to 54 Mbps (dynamic) 2.4 GHz 11n: up to 400 Mbps (dynamic) 11g: up to 54 Mbps (dynamic) 11b: up to 11 Mb/s (dynamic) |
| Receiver sensitivity | 5 GHz: 11ac VHT80: -62dBm 11ac VHT40: -64dBm 11ac VHT20: -68dBm 11n HT40: -71dBm 11n HT20: -73dBm 11a 54 Mb/s: -77dBm 2.4GHz: 11n HT40: -70dBm 11n HT20: -71dBm 11g 54 Mbps: -73dBm 11b 11 Mb/s: -87dBm |
| EIRP | 5 GHz: 20 dBm (FCC) / 20 dBm (CE) (EIRP) 2.4 GHz: 18 dBm (FCC) / 18 dBm (CE) (EIRP) |
| Wireless modes | Infrastructure mode |
| Security of wireless transmission | WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Other | |
| Certificates | FCC, CE, RoHS |
| Contents of the package | Archer T3U Plus Quick Installation Guide CD |
| System requirements | Windows 10/8.1/8/7 (32/64-bit), macOS |
| Work environment | Permissible operating temperature: 0℃~40℃ (32℉~104℉) Permissible storage temperature: -40℃~70℃ (-40℉~158℉) Permissible air humidity: 10%~90%, non-condensing Permissible storage humidity: 5%~90%, non-condensing |
Archer T3U Plus works in 5GHz and 2.4GHz.
The device supports USB 3.0 port
