Ubiquiti PBE-5AC-GEN2-5 | CPE | PowerBeam, AC 5GHz, 1x RJ45 1000Mb/s, 25dBi, 5-pack

CODE: PBE-5AC-GEN2-5-EU / EAN: 0817882020800

Ubiquiti PBE-5AC-GEN2-5 | CPE | PowerBeam, AC 5GHz, 1x RJ45 1000Mb/s, 25dBi, 5-pack

CODE: PBE-5AC-GEN2-5-EU / EAN: 0817882020800
460,64 GBP without VAT (net)
Out of stock
Number of LAN ports: 1x 10/100/1000BaseTX (RJ45)
Operating frequency: 5 GHz
Antenna gain: 21dBi - 30dBi
Show more parameters
Numbers of pieces in the package:
1-pack
5-pack

About product

Wi-Fi wireless radio management

PowerBeam AC integrates separate Wi-Fi for quick and easy configuration with a mobile device.

Improved mounting system and surge protection

Equipped with increased protection against ESD events, the PowerBeam AC offers a more robust mount with a comfortable clamp or lifting handle.

esd 5ghz 25dbi

Integrated radio architecture

Ubiquiti's InnerFeed technology integrates the radio with the antenna tube, so there is no need for cables to connect the radio with the antenna.

innerfeed ubiquiti POWERBEAM 5AC

Plug and Play installation

PowerBeam AC does not require any tools, only one key is needed to mount on the pole.

plugandplay powerbeam ac

A breakthrough in productivity

airMAX ac devices offer improved lag resistance, interference resistance, scalability and significantly increased performance.

Excellent data processing

Ubiquiti's airMAX mechanism with a custom chipset significantly improves TDMA delay and network scalability. The custom processor provides hardware acceleration capabilities of the airMAX planner to support high data transfer rates and dense modulation used in airMAX ac technology.

Amazing Beam antenna performance

The PowerBeam AC has the highest gain due to its size. The excellent orientation of the PowerBeam AC beam provides the best performance in high noise environments.

powerbeam ac 5ghz

AirOS 8 software

airOS 8 provides advanced features including support for airMAX ac protocol, real-time radio signal analysis and a completely new design for increased efficiency.

Specification

Features / filters
LAN standard Gigabit Ethernet 10/100/1000 Mb/s
Number of LAN ports 1x 10/100/1000BaseTX (RJ45)
Operating frequency 5 GHz
Antenna gain 21dBi - 30dBi
Antenna gain level (max) 25
DC input voltage 24
DC-in jack Yes
Device type Client device
Dimensions (WxDxH) 420 x 420 x 230
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
Frequency band 5
Harmonized System (HS) code 85176990
Internal memory 64
LED indicators LAN, Power
Maximum data transfer rate 400
Numbers of pieces in the package 5-pack
Operating relative humidity (H-H) 5 - 95
Operating temperature (T-T) -40 - 70
Power LED Yes
Power source type DC
Processor model Atheros MIPS 74Kc
Product colour White
Product type Network repeater
Quality of Service (QoS) support Yes
RAM capacity 64
RAM memory 64MB
Type of device power supply Passive PoE
Wall mountable Yes
Weight 2.22

Basic technical parameters
Dimensions 420 × 420 × 420 × 230 mm
Weight 2.22 kg
Power supply 24 V, 0.5A Gigabit PoE Adapter (included)
Maximum power consumption 8,5W
Power supply method Passive PoE (pairs 4, 5+; 7, 8 Return)
Voltage range supported 20 to 26VDC
Strengthening 25 dBi
Network interface (1) 10/100/1000 Ethernet port
CPU specification MIPS 74Kc
Memory 64 MB
LEDs Power supply,
Ethernet,
(4) Signal strength
Channel size PtP mode 10/20/30/40/50/60/80 MHz
PtMP mode 10/20/30/40 MHz
Characteristics of the housing UV-stabilized plastic antenna
SPCC powder-coated headlamp
Mounting kit On the pole (included)
Wind load 380 N at 200 km/h
Survival of the wind 200 km/h
ESD/EMP protection air ± 24 kV, contact ± 24 kV
Operating temperature -40 to 70° C
Working humidity 5 to 95%
RoHS compliance Yes
Rust resistance test IEC 68-2-11 (ASTM B117), equivalent to: MIL-STD-810 G Method 509.5
Vibration test IEC 68-2-6
Temperature shock test IEC 68-2-14
UV test IEC 68-2-5 at 40° C (104°F), equivalent: ETS 300 019-1-4
Rain test ETS 300 019-1-4, equivalent to: MIL-STD-810 G Method 506.5
Certificates CE, FCC, IC

Support

Software Download
Datasheet Download
Quick start guide Download

Faq

How to access airOS via Wi-Fi?

Są dwie możliwości albo przez portal internetowy, albo przez aplikację mobilną. Obie metody sa dostępne przez 15 minut od włączenia urządzenia. W razie potrzeby można włączyć ponownie urządzenie.

1. Pobierz aplikację UMobile z App Store (iOS) lub Google Play (Android).
ubiquiti powerbeam ac

2. Podłącz Wi-Fi urządzenia do PowerBeam SSID nazwany: PBE-5AC-Gen2:MAC Address

Uwaga: Upewnij się, że DHCP jest włączony na Twoim komputerze.

3. Uruchom aplikację.

4. Stuknij PowerBeam na ekranie połączenia.
ubiquiti powerbeam ac

5. Stuknij przycisk Połącz na ekranie logowania.
ubiquiti powerbeam ac

6. Wybierz swój kraj i dotknij przycisk gotowe.
ubiquiti powerbeam ac

7. Dostosuj ustawienia zgodnie z potrzebami.

ubiquiti powerbeam ac

At what temperatures can the device operate ?

Operating temperature: -40 to 70° C

What is the frequency of operation ?

Frequency of operation: 5GHz
