Ubiquiti UA-Intercom | Video intercom | indoor/outdoor

CODE: UA-INTERCOM / EAN: 0810084693841

Ubiquiti UA-Intercom | Video intercom | indoor/outdoor

CODE: UA-INTERCOM / EAN: 0810084693841
251,17 GBP without VAT (net)
Out of stock
Access chip/card reader: Yes
Access code reader: Yes
Authentication type: Access chip/card, Password
Bluetooth: Yes
Show more parameters

About product

Ensure security and convenience with Ubiquiti UA-Intercom !

This advanced video intercom offers unparalleled functionality and high build quality to manage residential and commercial entry requests in a modern and secure manner . With support for PoE, NFC and Bluetooth, the UA-Intercom is ideal for residential and commercial buildings, providing remote access control and monitoring.

UBIQUITI UA-INTERCOM INDOOR/OUTDOOR INTERCOM TERMINAL

Versatile mounting options

The Ubiquiti intercom can be easily mounted on a wall or pole with the included mounting accessories. Optional kits allow for surface or recessed mounting, allowing you to customize your installation to meet your specific needs. Wall or pole mounting for cameras provides installation flexibility in a variety of locations. Weatherproofing (IP65) makes the unit ideal for outdoor applications, regardless of the weather. A professional wall or pole mount ensures stability and durability of the installation.

UBIQUITI UA-INTERCOM INDOOR/OUTDOOR INTERCOM TERMINAL

Advanced security technologies

The video intercom supports NFC and Bluetooth 4.2, which enables convenient and secure access management via NFC cards and mobile devices. ESD/EMP protection function provides additional protection against electrostatic discharge and electromagnetic pulses. Multi-layer data encryption and compliance with UL 294 and CAN/ULC-60839-11-1 standards guarantee the highest level of security. The device, which works in conjunction with the Access Intercom, enables visitor control and remote access control.

UBIQUITI UA-INTERCOM INDOOR/OUTDOOR INTERCOM TERMINAL

Advanced functionality

The Ubiquiti UA-Intercom features a 7-inch display with a resolution of 1024 x 600, providing a clear image and ease of use. With capacitive multi-touch technology, the interface is intuitive and responsive, enabling easy management of residential and commercial entry requests. A 3264 x 2448 (8 MP)camera with a wide viewing angle provides excellent image quality, enabling accurate monitoring of the environment. The device uses multi-layer data encryption, which increases the security of communications.

UBIQUITI UA-INTERCOM INDOOR/OUTDOOR INTERCOM TERMINAL

Easy-to-use interface

The Ubiquiti UA-Intercom features a display that works with the Access Intercom to easily manage building access. With the UniFi Access app, you can remotely monitor and control building access using your smartphone. The ability to unlock the door with a PIN code, NFC card or mobile app provides flexibility and convenience.

Specification

Features / filters
Access chip/card reader Yes
Access code reader Yes
Authentication type Access chip/card, Password
Bluetooth Yes
Bluetooth version 4.2
Brightness adjustment Yes
Built-in display Yes
Built-in speaker(s) Yes
DC voltage range 48
Depth 28.3
Display diagonal 17.8
Ethernet LAN (RJ-45) ports 1
Ethernet LAN data rates 1000
Fingerprint reader No
Front camera Yes
Front camera type Single camera
Height 324.8
Housing material Aluminium, Glass, Polycarbonate (PC), Stainless steel
International Protection (IP) code IP65
Maximum image resolution 3264 x 2448
Maximum resolution 1024 x 600
Mounting bracket(s) included Yes
Near Field Communication (NFC) Yes
Number of speakers 1
Operating relative humidity (H-H) 5 - 90
Operating temperature (T-T) -30 - 60
Power consumption (max) 13
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 1
Product colour Black
Remotely operated Yes
RFID frequency 13.56
RFID reading distance 3
Screen shape Flat
Speaker power 2
Sustainability certificates CE, Federal Communications Commission (FCC)
Sustainability compliance Yes
Temperature alarm Yes
Total megapixels 8
Touchscreen Yes
Touchscreen technology Capacitive
Weight 965
Width 113.7

Technical data
Dimensions: 324.8 x 113.7 x 28.3 mm (12.8 x 4.5 x 1.1").
Weight: Device - 965 g (2.1 lb), Handle - 445 g (1 lb)
Housing material: Aluminum alloy, UV-stabilized polycarbonate, glass
Mounting material: Powder-coated stainless steel
Assembly: Wall mounting, gooseneck post adapter (included), surface mounting, recessed mounting
Protection Class: IP65
Network interface: (1) GbE RJ45 port
Connectivity: Bluetooth 4.2, NFC
Power method: PoE
Maximum energy consumption: 13W
Sensors: Proximity sensor, ALS sensor
Camera: 3264 x 2448, 8 MP, H: 79.4°, V: 97.5°, D: 118.2
Display: 177 mm (7") diagonal, 1024 x 600 (16:9) resolution, brightness max. 1000 nits, multi-touch capacitive touch technology
Microphone: Yes
LEDs: (1) LCM low-temperature indicator: orange (LCM off when the temperature is below -25° C, the system operates normally), (1) LED spotlight, (13) LED keypad backlight
NFC Reading Range: < 30 mm
Operating humidity: 5 to 90% non-condensable
Certificates: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
Management software: UniFi Access: version 1.22.17 and later

Faq

Is the Ubiquiti UA-Intercom video intercom weatherproof?

Yes, UA-Intercom is IP65 rated, which means it is resistant to rain and other harsh weather conditions, making it ideal for outdoor applications.

Does the video intercom support NFC and Bluetooth?

Yes, UA-Intercom supports both NFC and Bluetooth 4.2, enabling convenient and secure access management with NFC cards and mobile devices.

What are the advantages of using a PIN and NFC card to unlock the door?

Using a PIN code and NFC card to unlock the door provides flexibility and convenience, allowing different access methods depending on the user's preference.
