Ubiquiti UCG-Ultra EU | UniFi Cloud Gateway | 4x GbE RJ45 LAN, 1x 1/2.5GbE RJ45 WAN, USB-C, Bluetooth


EN
Ideal for managing modern networks, it offers high-speed WAN and LAN connections, as well as intuitive management via UniFi Network. With its compact design and advanced capabilities, the UCG-Ultra EU is ideal for demanding users.
The UniFi gateway is equipped with a quad-core ARM Cortex-A53 processor clocked at 1.5 GHz, 3 GB of DDR4 memory and 16 GB of eMMC memory. This ensures unmatched performance and stability of operation, even under heavy network load. So you can enjoy smooth operation and fast data transfer.
The gateway supports redundant WAN connections with failover and load balancing to ensure continuous Internet connections. In addition, the UCG-Ultra EU supports WiFi QoS with UniFi access points, application and device identification, and content and security filtering. All of this ensures that your network runs smoothly and without disruption.
With Bluetooth support and an Ethernet management interface, configuration and operation of the gateway is intuitive and simple. The UniFi Network app, available for iOS and Android, allows you to remotely manage your network from your smartphone, allowing you to quickly respond to changing network needs.
Features / filters | |
AC adapter included | Yes |
Built-in processor | Yes |
Cables included | LAN (RJ-45) |
Cabling technology | 10/100/1000Base-T(X) |
Certification | CE, FCC, IC |
Control display unit | Yes |
Depth | 127.6 |
DHCP server | Yes |
Enclosure material | Polycarbonate (PC) |
Ethernet LAN (RJ-45) ports | 4 |
Ethernet LAN data rates | 1000 |
Firewall security | Yes |
Flash memory | 16384 |
Height | 30 |
Input voltage | 100 - 240 |
Internal memory | 3072 |
Internal memory type | DDR4 |
LED indicators | LAN |
Manual | Yes |
Number of processors installed | 1 |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | -10 - 40 |
Output current | 3 |
Output voltage | 5 |
Power consumption (max) | 6.2 |
Processor family | ARM Cortex |
Processor frequency | 1500 |
Processor manufacturer | ARM |
Processor model | Cortex-A53 |
Product colour | White |
Quality of Service (QoS) support | Yes |
Reset button | Yes |
VLAN support | Yes |
WAN connection | Ethernet (RJ-45) |
Weight | 520 |
Width | 141.8 |
The Ubiquiti UCG-Ultra EU offers exceptional performance with a quad-core ARM Cortex-A53 processor, 3GB of DDR4 memory and 16GB of eMMC storage. It supports advanced networking features such as redundant WAN connections, WiFi QoS and application and device identification.
Yes, the gateway supports LAN connections of up to 1 GbE and WAN connections of up to 2.5 GbE for fast and stable data transfer.
Yes, with support for Bluetooth and the UniFi Network app for iOS and Android, setting up and managing the device is intuitive and easy.
