With the help of Wi-Fi WRE6505 V2 amplifier it will be possible to eliminate places where the current Wi-Fi network has a weak range. After quick configuration it will be possible to connect to the network even from distant positions.
To connect the WRE6505 V2 amplifier to an existing network, it is enough to use the WPS button on it and on the router or other gateway. The Zyxel WRE6505 V2 amplifier will be configured according to the parameters of the existing network and will provide Wi-Fi signal over a longer distance. The Zyxel ONEapplication will help you copy settings from your Zyxel ONEcompatible router for a seamless roaming connection.
The WRE6505 V2 amplifier allows to amplify network coverage in the following ways:
Zyxel WRE6505 V2 will help you to choose the best place to place it so that the network signal is the best and will indicate it with LED lights.
If you place the WRE6505 V2 amplifier in your bedroom, you can turn off the LED lights by pressing the WPS button three times. Its small dimensions will allow to place it in practically any place.
Features / filters | |
Number of LAN ports | 1x 10/100BaseTX (RJ45) |
Operating frequency | Dual Band (2.4GHz, 5GHz) |
Wireless network standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11ac, |
AC input frequency | 50 - 60 |
AC input voltage | 100-240 |
Automatic channel selection | Yes |
Cables included | LAN (RJ-45) |
Cabling technology | 10/100Base-T(X) |
Certification | CE LVD, CE, FCC |
Data transfer rate | 433 |
Depth | 45.2 |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN data rates | 10,100 |
Firmware upgradeable | Yes |
Harmonized System (HS) code | 85176990 |
Height | 77.8 |
LED indicators | Power, WPS |
Mounting type | Wall |
Operating relative humidity (H-H) | 10 - 90 |
Operating temperature (T-T) | 0 - 40 |
Package depth | 122 |
Package height | 95 |
Package weight | 243 |
Package width | 138 |
Product colour | White |
Quick start guide | Yes |
Security algorithms | WPS |
Storage relative humidity (H-H) | 10 - 95 |
Storage temperature (T-T) | -30 - 70 |
Type | Network transmitter & receiver |
Weight | 88.6 |
Wi-Fi | Yes |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
Width | 54.8 |
WPS push button | Yes |
System specification | |
Wi-Fi standards | 802.11 a/b/g/n/ac |
Transmission speed | Sending: -2.4 GHz: 300 Mb/s -5 GHz: 433 Mb/s Pick up: -2.4 GHz: 300 Mb/s -5 GHz: 433 Mb/s |
WLAN features | Universal relay mode Access point mode Wi-Fi Protection Setup (WPS) Wi-Fi Multimedia (WMM) Automatic channel selection Wireless network operation time management Wireless power output management Filtering of MAC addresses Range mode settings |
System management | Online software update |
Hardware specification | |
LAN | 1 x 10/100 Mb/s Ethernet RJ-45 port |
LEDs indicating | Power supply/WPS (blue) 2.4 GHz WLAN (white: 1-poor connection, 2-average connection quality, 3 good connection) 5 GHz WLAN (white: 1-weak connection, 2-average connection quality, 3 good connection) |
Buttons | WPS |
Power supply | 100-240 V AC, 50/60 Hz |
Physical specification | |
Dimensions of the device | 54.8 x 45.2 x 77.8 mm (2.16 x 1.78 x 3.06") |
Packaging dimensions | 138 x 122 x 95 mm (5.43 x 4.80 x 3.74") |
Weight | 88.6 g (0.20 lb) 243 g (0.54 lb) per package |
Package contents | Wireless range amplifier Ethernet cable Quick start guide with warranty card |
Environmental specification | |
Working conditions | Temperature: 0°C to 40°C (32°F to 104°F) Humidity: 10% to 90% (non-condensing) |
Storage conditions | Temperature: -30°C to 70°C (-22°F to 158°F) Humidity: 10% to 95% (non-condensing) |
Certificates | |
Security | CE LVD |
EMC | CE, FCC |
Operating instructions | Download |
Thanks to the Zyxel WRE6505 V2 amplifier, you will be able to increase the range of your wireless network, so that you can use it in a place far away from its source without losing quality.
The Wi-Fi WRE6505 V2 amplifier should be connected to any power outlet, but it is worth to pay attention to the suggestions of the connection quality indicator and adjust the place of its connection.
To switch off the LED lights on the network amplifier WRE6505 V2 it is enough to press the WPS button on it three times.
